10000 Gallon 38000L Petroleum Tank Semi Trailer Aluminum Alloy Tanker Trailer

10000 Gallon 38000L petroleum Tank semi Trailer aluminum alloy tanker trailer

These tanks and trailers are designed for transporting diesel, gasoline and other aviation fuels.

They are desinged to carry any liquid items like fuel, acid, water, diesel Jet A1 and else. We have different Tanker Trailers opportunity starts from 20.000 Liter to 60.000 Liter capacity. with 2 to 7 compartments.

Tanker trailer Specifications
Tank Body
Shape	Round
Dimension	11500mm2490mm3850mm or customized
Volume(m3)	38000L
Tare weight	About 9500kg
Tanker Body	4mm, aluminum alloy
End Plate	5mm, aluminum alloy
Manhole Cover	2 pcs
Discharging Valve	56 Diameter is 3 inch ball valve
Discharging Pipe	3” rubber hose, 2 pcs, 6m/each
Bottom Valve	1, guard against the oil leak event
Other	Ladder/ Walking Platform/ Folding armrest
Compartments	1
Chassis
Main Beams	Special design I beam, Q345 carbon steel material
Frame Beam	Upper plate is 14mm and lower is 16mm,middle is 8mm. height is 500 mm
Axle	3 axles, American type, FUWA brand.
Landing Gear	(D200T) 28T JOST brand
King Pin	2.00 or 3.5 inch bolt-in or welding king pin, JOST brand
Suspension	Mechanical spring suspension
Leaf Spring	90mm(W)16mm(T)10 Layer
Pneumatic Braking System	6 relay valve, 3 axles synchronization, WABCO brand
Tire	11.00R20, 12.00R22.5, 315/80R22.5 Double coin Brand
ABS	4S/2M
Accessories	Standard tool box, spare wheel carrier , Water tank
Voltage	24V
Packing and shipping
Painting	Complete Chassis sand blasting to clean rust, 2 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms	By Bulk Cargo/RORO

Our advantages:

1. Fudeng’s custom engineered Petro-Chemical trailers are the lightest on the market.

2. Proven two-piece barrel design with a single circumferential seam.

3. Industries widest sheet material minimizes barrel seams.

4. Designed for ease of operation and simple maintenance.

5. A wide variety of piping, vapor recovery, and pumping options available, including, factory-applied Tnemec Lining.

The basic equipment is of valves, manhole, baffles, pipes, ladder, etc.

For optional equipment, pump, dispenser, water box, tool box, EU subsea valve, static electricity wire coil, gasoline vapor recovery unit, spill-free alarm, bottom loading devices, etc.

10000 Gallon 38000L Petroleum Tank Semi Trailer Aluminum Alloy Tanker Trailer

You can tell us your requests, we customize for you!
