80T 60m3 Four Axles Cement Tanker Semi Trailer With Air Compressor

    Buy cheap 80T 60m3 Four Axles Cement Tanker Semi Trailer With Air Compressor from wholesalers

    Buy cheap 80T 60m3 Four Axles Cement Tanker Semi Trailer With Air Compressor from wholesalers
    • Buy cheap 80T 60m3 Four Axles Cement Tanker Semi Trailer With Air Compressor from wholesalers
    • Buy cheap 80T 60m3 Four Axles Cement Tanker Semi Trailer With Air Compressor from wholesalers

    80T 60m3 Four Axles Cement Tanker Semi Trailer With Air Compressor

    Ask Lasest Price
    Brand Name : Fudeng
    Model Number : SDFD03
    Certification : CE, ISO9001, CCC
    Price : negotiation
    Payment Terms : T/T, L/C or negotiate
    Supply Ability : 600 sets per month
    Delivery Time : 25-40 days after 30% deposit
    • Product Details
    • Company Profile

    80T 60m3 Four Axles Cement Tanker Semi Trailer With Air Compressor

    80 T 60 m3 cement bulker tank trailer with air compressor four axles



    Widely praised as the industry’s most cement dry bulk trailers,Fudeng Trailer offers vessel integrity, low tare weights, high efficiency, long wear, easy cleanout and Fudeng Trailer craftsmanship throughout, to keep your operation running at maximum efficiency. Fudeng Trailer dry-bulk trailers have all the qualities desired in an efficient solution, It’s Fudeng Trailer craftsmanship, combined with the exceptional durability, thoughtful engineering and high payloads customers have come to expect from every premium Fudeng Trailer product—peace of mind that frees you up to focus on the most important project of all—building your business.


    Bulk Cement/Powder Transport Semi Trailer
    Rated Load40000 kg- 80000 kg
    Tare Weight10000/9100 kg
    Wheel Base5600+1310+1310 (mm)
    Tyre Specifications11.00R20 12PR
    No. Of the Tyres12
    Axle13Tonnage
    No. Of the Axles3
    Axle-load13000 kg
    Pieces of leaf-spring10
    SuspensionLeaf spring suspension
    Departure Angle32
    Front/Rear Overhang950 mm
    Main Beam MaterialQ345B manganese plates, automatic submerged arc welded
    Brake Systemdual-pipes braking system with automatic air chambers
    Brake Air Chamber6pcs
    Body thickness5mm
    Layer No.2
    Manhole3
    Diesel Engine4102
    Air Compressor12 cbm
    Landing GearDual line speed 28T
    Color and LogoAs the buyer’s request
    Electrical System24V, 7core socket, lights according to European standards.
    Tool Box1 box of standard tools
    Spare tire carrier1 set
    Color and LogoDepends on the buyer’s requirement.
    The traction pin3.5’ or 2’
    Pin HeightAccording to the height of the tractor saddle.

    80T 60m3 Four Axles Cement Tanker Semi Trailer With Air Compressor


    Our features:


    Filling Line

    Manhole lids and filling from top.


    Discharging Line

    Each feed funnel, corrosion decreasing, fast, easy to intervene in, not having blockage risk, flanged, bolt connected, direct discharging line with backside output by driving direction via DN 200 bottom output piping, and cam lock connected lid at output end. Welded joints strengthened with foreign reinforcement against corrosion.


    Air Line Installation

    Ergonomic, controlled and providing quick response opportunity, easy to reach, defined and systematic, providing pass of pressurized air coming from compressor to inside body, controlled, inside tank air inlet valve


    80T 60m3 Four Axles Cement Tanker Semi Trailer With Air Compressor
