    Gas Ammonia Liquid LPG Tank Trailer Volume 49.1 Cubic Meter Steel Material

    Gas Ammonia Liquid Tank Trailer Truck , 49.1cbm Lpg Tank semi Trailer


    LPG tank truck also called LPG transportation truck, gas tank truck. Our company focuses on producing various LPG container, LPG tank, LPG truck and LPG transformer. LPG transportation is high risk work, in order to keep the safety of LPG product use, we put our full energy to control the quality strictly. As Chinese well-known LPG equipment manufacturer and LPG equipment supplier, we can provide more LPG tank technical specification and spare part service. Please feel free to contact us for much more information on various LPG products.


    LPG semi trailer takes advantage of compression resistant tank for transporting the liquefied ,which is the special vehicles(For example propane, propylene, liquid ammonia, liquid nitrogen, liquid hydrogen, liquefied natural gas, liquid sulfur dioxide and so on).


    Specification



    Dimensions(l*w*h)


    12800*2495*3800(mm)

    Tare Weight15000KGPayload21000KG
    Volume50CBMTotal Weight36000KG
    Shell Of Tanker
    ProductsLPG, Butane , PropaneTemperature-40°C to 50°C
    Fluid propertyflammableDesign pressure1.61MPa
    Corrosion allowance1.0mmCompartmentsOne
    Materials of bearing pressureTanker body : Q345R , 12.5mm
    End plate : Q345R , front:10mm,Rear:12.5mm
    Main Beam : T700
    Baffle inside the tank14-off Aluminum bolted plate , thickness is 5mm
    ShapeCylindrical ; Ellipse head
    Manhole1On top
    Safety Valve2On the top ; Only weld suitable flange
    Liquid meterOn left side of tanker, Only weld suitable flang
    Valve and pipe DetailAs customer's requirement
    Running System
    Axles313 TON Axles
    Suspension system1Leaf spring suspension
    Wheel rim711.75*22.5
    Tyre712 R22.5 vacuum
    Kingpin190#/50#
    Landing legs128Ton
    Pneumatic braking system with double air chambers per axle
    Electronical System
    7-Pin Socket124V 7-pin socket
    LED Lamp1All kinds of lamp
    Cable1Stander cable
    Accessories
    Small Tool box1
    Wheel carrier1
    Fire extinguisher2With red box
    Cabinet1
    Plastic fender6
    Static conductive belt1
    Impeller blasting1Completely
    Paint1As customer requirements


    LPG Tank semi trailer


    Gas Ammonia Liquid LPG Tank Trailer Volume 49.1 Cubic Meter Steel Material


    LPG Tanker


    Gas Ammonia Liquid LPG Tank Trailer Volume 49.1 Cubic Meter Steel Material
