    Oil Tanker Trailer With Lifting Front Axle , Tanker Truck Trailer Q345 Carbon Steel

    Ask Lasest Price
    Brand Name : Fudeng
    Model Number : FDZH33126
    Certification : ISO CCC CQC
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 2400 sets per month
    Delivery Time : 30 working days for fuel tanker semi trailers
    Price : negotiation
    • Product Details
    • Company Profile

    Oil Tanker Trailer With Lifting Front Axle , Tanker Truck Trailer Q345 Carbon Steel

    Heavy oil tanker truck price , 3 axle fuel tanker trailer with lifting front axle

    The fuel tanker trailer is commonly used to be transfer diesel fuel, petrol, crude oil, edible oil, palm oil, and liquid asphalt etc...

    As a specialist in the manufacture of military tanker trailer, we have pioneered the application of the plate
    bender and welder in the manufacture of the fuel tanks. Our industry leading design capability allows us to supply your desire tanker trailer in the shortest possible time. We are an ISO9001 certified company.

    Our specially constructed tank transporters have taken up great market share of the Africa and South-East Asia markets. We can sell complete knock Down kits or semi knockdown kits to our valued
    oversea clients.

    Specification

    Overall length11900*2500*3850mm
    TypeSteel self-support fuel tanker with 6 compartment,with the necessary baffles
    Capacity42000L
    MaterialCarbon steel Q345,tank:4.5mm thickness,
    Dished end5.5mm thickness,baffle:4.5mm thickness
    Manhole6 manhole covers with filling opening and auto-pressure relief valve to control pressure built by temperature variation.
    Discharge valveEvery compartment will be fixed one unit aluminum alloy foot valve and one unit API discharge valve with API Dust Cap.
    Access ladderOne(1) access ladder at front of tank.
    WalkwayFor easy access to manholes covers(material is carbon steel)

    Axles
    BPW ECO 12 ton capacity,three unit,Hub odometer for kilometers on one unit
    SuspensionsAir bag suspensions, front axle liftable
    Tire and rimSuper single Double Coin tire 385/65R22.5 on steel rim
    Break systemDouble line air breaks with spring loaded parking brake,air parking brake,ABS installed.(Mudguard for one steel unit)
    Electrical lightElectrical equipment 24 Volt,in accordance with the road traffic regulations electric connection type SAE 7 poles mounted on the front bearer.

    Loading:
    Bottom and top loading with overfill sensors(British Standard)to prevent overfilling during the bottom loading operation
    Accessories:

    Side protection bumper
    8 liters fire extinguisher
    50L water tank
    Small plastic tools box
    2’Kinpin



    Oil Tanker Trailer With Lifting Front Axle , Tanker Truck Trailer Q345 Carbon Steel Oil Tanker Trailer With Lifting Front Axle , Tanker Truck Trailer Q345 Carbon Steel

    1 . There are plate in each compartment , to decrease the shake of fuel / oil during the transportation .

    2 . Welding the wire fabricfor walking plateform on the tank , to guarantee your safety .

    Oil Tanker Trailer With Lifting Front Axle , Tanker Truck Trailer Q345 Carbon Steel
    We can produce many types of semi trailer and full trailer even trailer parts .
    if no trailer is your like , you can tell me your actual requirements , customized is available .

    Sincerely,
    You are welcome to visit our factory!

    Wish long time cooperation can be built by our joint effort!
