50 tonne Gooseneck low bed semi truck trailer for heavy equipment transport

Low bed semi trailer is a multi functional transport vehicle which offers the optimal economic and technical solution to different transport tasks such as construction machines, farming machines, lifting vehicles, industrial parts and much more.

General
Overall Dimension	11960mm3000mm3300mm
Flatbed Dimension	8000mm*3000mm
Tare Weight	9630kg	Pay Load	60ton
King Pin Setting	450mm	Rear Overhang	1870mm
Wheel base	7950mm+1305mm+1305mm	Loading Surface Height	1320mm
Track	2160mm
Running Gear
Suspension	Tri-axle 8-pcs leaf spring suspension with equalizer beam
Tires	311.00-20, 11.00R20,12.00-20,12.00R20 12units
Axles	AQ,FUWA, BPW or STEYR axle, 13T capacity
Brakes	Dual lines pneumatic brake system, WABCO Emergency Relay Valve; T30/30+T30 air chamber; parking brake
Under Frame
Main Beam	I shape, Mild Alloy (16Mn) by Automatic submerged arc welding.
Cross Beam	Mild Alloy Q235, 16# channel beam
King Pin	Size: 50# (2'') or 90#(3.5’’); Type: welded or assembled
Landing Gear	Single side operation or double side operation, Static capacity 30Ton
Flatbed Floor	Checkered sheet, thickness 4mm
Rear Ladders	Spring power-assisted
Electrical & Paint
Lights & Reflectors	Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light

STANDARD FEATURES

· Payload 50,000kg
· Rear Lights on Ramp & Inside Well of Beavertail
· Mudguards Front and Rear
· Parking Brake
· Well in Beavertail
· Sprung Assisted Ramps – 6mm steel plated with Gripper Bars

OPTIONAL FEATURES

· Wide Sprung Ramps – Maximum 720mm
· Hydraulic Ramps – 600mm to 900mm
· 3mm Steel Strips under Timbers for supporting Wheeled Machines
· Cord fastener
· Tool Box – Front / Side
· Colour

Welcome to contact us to get more information.
