V type 3 axle 45cbm 60tons bulk cement tanker trailer / ash semi
trailer with BPW axle
FUDENG BULK CEMENT TANK TRAILER -- SHANDONG FUDENG AUTOMOBILE
CO.,LTD
Product Description
1, We have well experienced in reseaching and developing different
trailers: Container trailer, low bed trailer, side wall semi
trailer, stake semi trailer, tank trailer and heavy duty trailer
etc.
2, High tensile strength steel Q345B
3, Axle: German or American style from 12 tons to 20 tons
4, Suspension: Mechanical suspension, air suspension or
bogiesuspension.
5, Tyre: 10.00R20, 10R22.5, 11.00R20, 11R22.5, 12.00R20 or 12R22.5
(Other size is optional)
6, King pin: Optional for 2" or 3.5" Kingpin
7, Landing gear: "Jost" landing gear
Specification
| Bulk Cement Tanker Semi Trailer |
| Assembly | Composition | Specification |
Optional |
Dimensions | Size(LxWxH) | 12980*2500*3950mm | |
| Curb weight | 15500kg | |
| Loading weight | 60000kg | |
| Tank volume | 40-80m³ | |
| Box thickness | 6mm | |
| Chassis | Main beam | Q345 Steel; The height of the beam is 500mm; Upper plate is 16mm;
Middle plate is 8mm; Downplate is 16mm. |
|
Cross beam | 16# channel steel | |
| Side beam | 25# channel steel | |
| King pin | 2'' or 3.5'' traction pin | Optional JOST |
| Support leg | China brand 28Tons (Double speed) | |
| Suspension | Type | Common mechanical | Optional Air suspension |
| Steel spring | 90(W)mm*13(Thick)mm*10 Layer | |
| Axle | Brand | Fuwa(13000kgx3) | Optional BPW |
| Wheel rim | 9.0-22.5 steel wheel rim | |
| Tire | 12.00R22.5 Double Coin Brand(12 pcs) | Optional 12.00-20 |
| Brake system | Brake chamber | WEBCO, 6 big chamber | |
| Brake valve | KTL/WEBCO | |
| Brake syste | Dual line brake system | Optional ABS |
Details
FAQ
1. MOQ: 1 Unit
2. Optional payment terms: T/T or L/C
T/T: 30% deposit by T/T, 70% balance should be paid before
shippment.
L/C: 30% payment advance, 70% L/C at sight.
3. Parts of famous brand can be adopted by your requirement, such
as WABCO, JOST, BPW, FUWA.
4. Delivery time: Within15 workdays after receiving 30% deposit of
T/T
Business scope
Flatbed trailer, Low bed trailer, fuel tanker trailer, Cement
tanker trailer, Container side lifter, Car Carrier Trailer, Dump
truck trailer, Skeletal semi trailer, Extendable trailer ect.
We supply truck trailer with good quality and very competitive
price !
We hope to be a partner of your company !
If you need latest price ,we will provide !
Any reply will be highly appreciated.
