3 axle flatbed truck trailer for sale 40ft or 20ft container delivery trailer

Ask Lasest Price
Brand Name :	Fudeng
Model Number :	SDFD1704 Flatbed trailer
Certification :	CE, ISO, CCC, SGS, ADR
Payment Terms :	L/C, T/T or negotiate
Supply Ability :	600 sets per month
Delivery Time :	25-40 days after 30% deposit
Price :	negotiation

Add to Cart

Product Details
Company Profile

3 axle flatbed truck trailer for sale 40ft or 20ft container delivery trailer

Fudeng can offer different type or flatbed trailer for dry loads and containers. These kind of Flatbed Trailers are used for carrying container, steel bar, other items which is loaded with pallet and normal cargo laoders. Fudeng can offer Flatbed Trailers with different specification according to country regulations and customer demand from 20 tons to 70 tons.

Our Advantages:

1.We apply Underwater plasma machine to cutting steel material, which is more precise than high flame cutting and no deformation.

2. The main beam and side beam are reinforced, which can make the trailer more stable and heavy-loaded.

3. We use high-intensive twistlocks. They can be hiden to for various container transportation.

4. Thicken No.8 channel steel Diagonal bracing and 100mm frame make the chassis more solid.

5. The trailer parts were connected by bolts and nots, which is easy repair and duarable.

6. We use 6 air chamber, 3 axles synchronization to guarantee security when braking.

Flatbed semi trailer
Dimension (mm)	12,391 x 2,500 x 1,560
I-Beam	520 x 14 x 6 x 16
Wheel base(mm)	7800+1310+1310
Over hang( mm )	800mm
Tare(kg)	7500
Payload (kg)	40000
Total weight(kg)	47500
Twist Lock	12 pcs for delivery 140’, 220’, 1*20’ ISO Standard container
Kingpin	2” bolt kinpin, Brand JOST
Landing gear	Brand FUWA 28T 19”, right side operating
Tire size	11R20 , 13pcs, famous china brand
Rim size	8.0V*20, 10 Holes ISO, 13 pcs,famous china brand
Leafs spring	8 pcs (4 full length), 90x16mm
Axle	150x150 Square axle with 13 ton capacity/set FUWA
Suspension	CIMC Mechanical Suspension
Brake system	Dual line air brake system, no ABS brake system, WABCO brake valve
Air Chamber	30/30 type on each axle
Hook	10pcs on each side of the platform, rear:2pcs
Hole	8pcs on each side of the platform
Head board	500mm
Spare tire carrier	02 units
Floor	3.0mm checked plate
Tool Box	01 set with tools,1 m steel, on the right

3 axle flatbed truck trailer for sale 40ft or 20ft container delivery trailer
